Place of Origin:
China
Brand Name:
Relle
Model Number:
EN SERIES
TECHNICAL DATA
(If you need different specifications or characteristics, please contact us, relle team will serve you )
|
|
|
|
|||
DESCRIPTION
|
|
|
|
|||
Total thickness
|
EN428
|
mm
|
2.0/2.6/3.0
|
|||
Wear layer thickness
|
EN429
|
mm
|
0.4 / 0.5 / 0.7
|
|||
Weight
|
EN 430
|
g/m2
|
2500 /2800 / 3200
|
|||
Width
|
EN 426
|
mm
|
200
|
|||
Lenghth of sheet
|
EN 426
|
m
|
20/15
|
|||
CLASSIFICATION
|
|
|
|
|||
European classification
|
EN 649
|
class
|
34-43
|
|||
K rating
|
-
|
class
|
K5
|
|||
|
EN 13501-1
|
class
|
B(fl-s1)
|
|||
Fire rating
|
DIN 4102
|
-
|
B1
|
|||
|
GB8624-2006
|
-
|
GB 8624B(fl-s1)
|
|||
Toxic testing
|
GB 18586-2001
|
-
|
Qualified
|
|||
Static electrical propensity
|
EN1815
|
KV
|
<2
|
|||
Electrical resistance
|
EN1081
|
Ω
|
≥108-10
|
|||
Slip resistance dry
|
EN 13893
|
-
|
≥0.3
|
|||
Slip resistance wet
|
DIN 51130
|
class
|
R9
|
|||
PERFORMANCE
|
|
|
|
|||
Abrasion resistance
|
EN 660.1
|
mm
|
≤0.15
|
|||
Abrasion group
|
EN649
|
Group
|
T
|
|||
Dimensional stability
|
EN 434
|
%
|
≤0.4
|
|||
Residual indentation /
|
EN 433
|
mm
|
0.04
|
|||
Thermal conductivity
|
EN 12524
|
W(m・K)
|
0.25
|
|||
Colour fastness
|
EN20105-B02
|
Degree
|
≥6
|
|||
Chemical products resistance
|
EN 423
|
-
|
OK
|
|||
Anti-bacterial and fungicidal
|
-
|
-
|
OK
|
|||
Special maintenance treatment
|
-
|
-
|
UV
|
