Place of Origin:
China
Brand Name:
Relle
Model Number:
ESD ROLL
TECHNICAL DATA
(If you need different specifications or characteristics, please contact us, relle team will serve you )
|
|
|
||
Test Items
|
Standard
|
Result
|
||
Thickness
|
ISO 24346-EN430 SJAT11236-2001
|
2.0/2.5/3.0mm
|
||
Length(Static Dissipative)
|
ISO 24341-EN426 SJ/T11236-2001
|
15/20m
|
||
Width(Static Dissipative)
|
ISO 24341-EN426 SJfT11236-2001
|
2m
|
||
Size(Conductive)
|
EN427ASTM-F-536
|
600mm*600mm
|
||
System resistance
|
DIN 51953
SJ/T11236-2001
|
Static Dissipative 1.0×106~1.0×109Ω
Conductive< 1.0×106Ω |
||
Decay period of static voltage
|
SJ/T10694-2006
|
≤2S
|
||
Starting voltage
|
SJ/T11236-2001
|
IVI<100V
|
||
Amount of wear
|
SJ/I11236-2001
|
≤0.02g/cm2
|
||
Combustion property
|
GB8624-2006
|
Bf1-S1,t1
|
||
|
SJ/T11236-2001
|
FV-0
|
||
Smoke production
|
GB8624-2006
|
≤750%,min
|
||
Smoke toxicity
|
GB8624-2006
|
ZA3
|
||
Anti-bacterial
|
ISO 22196
|
Anti bacterial rate I
|
||
Slip resistance
|
DIN51130
|
R9
|
||
|
EN13893
|
≥0.3
|
||
Toxic testing
|
GB18586-2001
|
Suitable
|
||
Formaldehyde emission
|
EN717-1
|
N.D
|
||
Residual indentation
|
EN433
|
≤0.10mm
|
||
Effect of castor chair
|
EN425
|
NO delamination no cracks
|
||
Dimensional stability
|
EN434
|
≤0.40%
|
||
Color fastness
|
ENISO 105 B02
|
≥6级
|
||
Impact sound absorption vli
|
ENISO 0717/2
|
Approx 2dB
|
||
Resistance to staining
|
EN423:2001
|
0,Not affected
|
